Customized Hydraulic Swing Device compact Rotary Motor Swing Excavator

Customized Hydraulic Swing Device compact Rotary Motor Swing Excavator

Product Details:

Place of Origin: QingDao
Brand Name: Crystal
Certification: ISO9001 / EN ISO 12100 / OHSAS 18001 / SGS
Model Number: ZJMS-200

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sets
Price: Reconsideration
Packaging Details: Wood case
Delivery Time: 3-5days
Payment Terms: L/C, T/T
Supply Ability: 1000 Sets/month
Get Best Price Contact Now

Detail Information

Product Name: Excavator Swing Motor Brand Name: Crystal
Application: Excavator Machine Model: ZJMS-200
Warranty: Half One Year Delivery Time: Within 3 Working Days
Package: Wooden Box
High Light:

Customized Hydraulic Swing Device


Hydraulic Swing Device Compact


Rotary Motor Swing Excavator

Product Description

Excavator Swing Motor WackerNeuson17 Carter301.7 Hydraulic Rotary Motor

Product Description


Shaft end gear parameters
Modulus 4.0
Pressure Angle 20
Number of teeth 13
Large diameter 62.5
Small diameter 45
Addendum coefficient 1
Radial clearance coefficient 0.25
Modification coefficient 0.4
Base tangent length 19.42(2Tooths)


The motor parameters
Displacement(LPM) 38
Pressure(MPa) 9
Torque(N*m) 230
Rotate speed(ml/r) 140
Relief valve pressure(Mpa) 14-14.5Pressure drainage
The brake torque(N*m) 550-600
Starting pressure(Mpa) 0.98-2.9

Product parameter diagram:

Customized Hydraulic Swing Device compact Rotary Motor Swing Excavator 0

Product  advantage and peculiarity

Durability and Reliability verification: Our hydraulic rotary motors are rigorously verified for durability and reliability. We carry out a number of tests and simulations to ensure superior durability and reliability of rotary motors under a variety of operating conditions and load requirements. These validation processes include testing in extreme environments such as high temperatures, low temperatures and high loads to ensure that our rotary motors operate stably and meet your long-term needs.
Comprehensive after-sales service: We are committed to providing comprehensive after-sales service and support. Our after-sales team provides quick response and professional technical support to solve the problems you encounter during use. We also offer regular maintenance and maintenance services to extend the life of rotary motors and maintain their optimum performance.


Technological advantage

Customized Hydraulic Swing Device compact Rotary Motor Swing Excavator 1


High speed and high torque output: Our hydraulic rotary motors offer excellent speed and torque output. Through advanced hydraulic technology and optimized internal structural design, our rotary motors provide high rotation speed and high torque output, giving your equipment powerful rotation capability for fast and efficient operation.
Precision control and smooth performance: Our rotary motors are equipped with advanced control systems for precise rotation control. Through high-precision valves and advanced hydraulic regulation technology, our products enable smooth, precise rotation motion, providing superior operating experience and precise positioning to improve operational efficiency.
Lightweight design and compact construction: We focus on the advantages of lightweight design and compact construction to provide higher power density and more flexible installation methods. We use optimized material and structural design to reduce the weight and size of the rotary motor, making it more flexible in installation and layout to meet the needs of different excavator models and working environments.



Customized Hydraulic Swing Device compact Rotary Motor Swing Excavator 2


Product application range

Engineering construction: Hydraulic rotary motors are widely used in engineering construction fields, such as excavators, loaders, bulldozers, etc. They provide the equipment with strong turning capacity, flexible operation and accurate positioning, and adapt to a variety of engineering construction tasks, such as excavation, ground leveling, and soil stacking. The hydraulic rotary motor can be flexibly rotated in the narrow construction site to improve the construction efficiency.
Agricultural machinery: Hydraulic rotary motors are also widely used in agricultural machinery. For example, they are used in agricultural tractors, harvesters and spraying equipment to achieve turning and swinging actions in field operations. The high efficiency and reliability of hydraulic rotary motors enable agricultural machinery to efficiently complete various agricultural tasks and improve agricultural production efficiency.
Ports and logistics: In the field of ports and logistics, hydraulic rotary motors are widely used in various loading and unloading equipment, such as cranes, stackers and loading and unloading trucks. They provide high-speed, high-torque turning capabilities that enable equipment to turn and position quickly and precisely, improving logistics operation efficiency and loading and unloading speed.
Mines and quarries: Hydraulic rotary motors play a key role in the equipment used in mines and quarries. For example, they are widely used in equipment such as mine loaders, excavators and crushers to achieve rotary and positioning actions of equipment. The high torque and stability of the hydraulic rotary motor enable the equipment to operate efficiently under harsh working conditions and cope with high-intensity mining and crushing work.
Other fields: Hydraulic rotary motors are also suitable for other fields, such as Marine engineering, environmental cleaning equipment and special machinery. Whether in deep sea digging, environmental cleaning, special mechanical operations, or other applications requiring rotary action, hydraulic rotary motors provide reliable and efficient rotary capabilities.
